Fan Coils
KaCool W
design wall-mounted unit for heating and cooling
Overview
Our attractive and unobtrusive design wall-mounted unit demonstrates that steel and plastic complement each other perfectly. The high-quality and flat visible trim is only 185 mm wide. Only the cooled or heated air fed in can be pleasantly felt.
Thanks to the drilling template supplied: drill 4 x holes, screw in and the KaCool W's already on the wall. It couldn't be any simpler or more precise! And if you don't know what output you need in advance: now you know how easy it is to retrofit the KaCool W.
All the components are compactly installed inside the unit. Remove the trim and all components are easily within reach.
KaCool W units heat and cool both comfortably and hygienically. They comply with all all hygiene criteria (construction, components, cleanability and maintenance) and are therefore certified to VDI 6022.
The white finish of the KaCool W blends wonderfully into most interiors. Other colours are also available with (almost) no limits to your colour choice.
Heat Pump Ready
This product is suitable for use with a heat pump or other low temperature system. Reduce your energy requirements, operating costs and emissions with our Heat Pump ready range of products. And make you and your customers less dependent on fossil fuels.
We have appropriate heat pump solutions for many applications, from industrial sheds, office buildings, hotels to private homes.
→ Discover more
- Simple removal is possible
- The ISO Coarse air filter can be regenerated by simply vacuuming it
An extremely energy-efficient EC motor is fitted in the KaCool W, the continuously variable operation of which guarantees precise adaptation to the output requirement. It also stands out with its low noise emissions.
- High-output copper-aluminium heat exchanger
- With high heat and cooling outputs
- Optimised in terms of air flow
- Louvre fins, manually adjustable, motorised adjustment with infra-red remote control version
- For adjustable air distribution and fewer draughts in any space
Different valve kits are available: 2-way, 3-way and differential pressure-independent valves combined with matching pipe connections and actuators
Optionally available for reliable condensate drainage
Downloads
Declarations/Certificates
Certificate ISO 50001:2018
PDF
(194 kB)
Certificate ISO 9001:2008
PDF
(118 kB)
EU Declaration of Conformity KaCool W fan coils (FCU)
PDF
(173 kB)
Cross-product information
Products
PDF
(17.9 MB)
Fan Coil brochure
PDF
(9.6 MB)
Manuals
KaCool W Fan Coils (FCU)
PDF
(4.2 MB)
KaCool W, brief guide
PDF
(1.1 MB)
CAD-Drawings
Fan Coil KaCool W, Baugroesse 1 - 4, PDF
PDF
(382 kB)
Fan Coil KaCool W, Bohrschablone BG 1 - 2, PDF
PDF
(217 kB)
Fan Coil KaCool W, Bohrschablone BG 3 - 4, PDF
PDF
(221 kB)
Fan Coil KaCool W, Baugroesse 1 - 4, DWG
DWG
(551 kB)
Fan Coil KaCool W, Bohrschablone BG 1 - 2, DWG
DWG
(348 kB)
Fan Coil KaCool W, Bohrschablone BG 3 - 4, DWG
DWG
(350 kB)
Technical catalogues
KaCool W
PDF
(5 MB)
BIM data (Building Information Modeling)
Kampmann Group BIM data
